Direct replacement to your original unit.

Features:

  • Plug-and-play direct fit easy installation.
  • No assembly required.
  • Higher grade of electric components.
  • Improved heat sink and charging capabilities.
  • The quality exceeds the OEM equipment.
  • All products shipped are tested.

Specifications:

  • Width: 79 mm
  • Length: 109 mm
  • Height: 28 mm
  • Wire Length: 540 mm
  • Mounting Hole Centre-to-Centre Distance: 80 mm
  • Number of Plugs: 2
  • Number of Pins: 7
  • Number of Wires: 7
  • Minimum Charging Voltage: 14.5 V ± 0.5 V
  • Maximum Charging Current: 50 A / 500 W
  • Open Circuit Voltage: < 15 V
  • Operating Temperature: -20°C to 85°C

(RMS020108440)

SKU RMS020108440
Barcode # RMS020-108440
Brand RMStator
Unit Of Measure each
