SW-Motech TRAX ADV Aluminium Case System for 2024-2026 Honda X-ADV

SW-Motech TRAX ADV Aluminium Case System - Silver

Fits: 2024-2026 Honda X-ADV

TRAX ADV Aluminum case System

SW-MOTECH manufactures this aluminum case System suitable for the Honda X-ADV with extremely resilient, bike-specific Pro Side Carriers.

TEST WINNER in the magazine MOTORRAD issue 05/2020. Test result: VERY GOOD

Durable TRAX ADV aluminum cases feel at home on any stretch of road: embossed patterns add stability to the 1.5 millimeter-thick, welded aluminum wall material. A completely removable lid with carrying handles made of anodized aluminum and quick release fasteners makes loading and unloading of motorcycle Luggage easier; the beveled side edge Provides high ground clearance when cornering. With this complete solution, you have all the components you need to travel with TRAX: two waterproof TRAX ADV Side Cases, two detachable SW-MOTECH Side Carriers, adapter kit, Lock Set, lid limiter and anti-theft Protection at an attractive price.

The bike-specific carrier and the size of the cases are perfectly matched to the rear shape and exhaust System of the motorcycle. A motorcycle case without compromise: the development of the TRAX ADV focused on stability and impermeability against dust and water as well as simple handling. Whether on an off-road Adventure, road trip or short haul, the premium aluminum case with a wall thickness of 1.5 millimeters will come out on top in any challenge.

PRO Side Carrier
- Extremely durable due to its optimized shape and 2.5 mm thick steel
- Perfect fit, designed to fit close to the bike
- Fully removable with newly developed, even more robust quick-release fasteners
- Optional anti-theft Protection available
- For permanent Mounting, quick-release fasteners can be replaced with standard Parts (M8)
- Numerous functional bores
- Simple Mounting on original Mounting points
- Powerful corrosion Protection thanks to powder coating
- Secure hold for TRAX, DUSC, AERO and SysBags WP L with adapter Plate
- Details
- Material: Steel
- Surface: powder coated
- Color: black
- Total Weight: appr. 4,2 kg / appr. 9.3 lb
- Width built onto motorcycle: 54,0 cm / 21.3 in
- Note
- Only in conjunction with STREET-RACK.
- Adapter kits are required for aluminum cases from SW-MOTECH and other manufacturers and also for AERO ABS Side Cases and SysBags with adapter Plates (SysBag 15, 30, WP L).
- Required for Mounting
- The Pro Side Carrier can only be Mounted together with the STREET-RACK.
Adapter Kit for Pro Side Carrier
- Adapter Kit for attaching a TRAX or NANUK Side Case to an SW-MOTECH Pro Side Carrier
- Mounted on to the existing holes of the SW-MOTECH Pro Side Carrier
- For Left and Right sides
- Details
- Color: silver
- Total Weight: appr. 0,3 kg / appr. 0.7 lb
TRAX ADV L Aluminium Case
- Model for the Left side of the motorcycle
- Protection against oxidation and abrasion thanks to black powder coating, easy to clean surface
- Sturdy and watertight Side Case made from aluminium
- Large chamfer on sides for plenty of ground clearance for cornering, additional Protection from glass fiber reinforced plastic corner caps
- Robot-guided welding and self-piercing riveting prevent dampness from getting in
- Even when loaded, completely removable lid with quick-release fastener
- 4 large tie-downs integrated into the lid design (e. g. for a tent or Accessory bag)
- High stability thanks to the embossed patterns, welded edges and pre-installed retaining rail
- Hinges made from stainless steel, handles made from anodized aluminum
- Lid limiters Provide additional stability when using extra Luggage on the lid
- Exchangeable Cover gasket
- The membrane makes it easy to open the lid, even in case of extreme pressure and temperature fluctuations
- Quick Mounting on to all Pro and EVO Luggage carriers (adapters sold separately)
- Adapter kits also available for Mounting on to girders from other manufacturers such as Givi and Hepco & Becker
- A Lock Set with 6 identical locks is available as an option and is not included in delivery
- Details
- Material: Aluminum
- Material strength: 0,15 cm / 0.06 in
- Surface: powder coated
- Color: black
- Size: 49,0 x 28,0 x 37,0 cm / 19.3 x 11.0 x 14.6 in
- Total Weight: appr. 5,4 kg / appr. 11.9 lb
- Total Volume: 0,0-45,0 l
- Note
- Also available as a TRAX ADV aluminum case System with 2 Side Cases, bike-specific Side Carriers, adapters and Lock Set.
- Required for Mounting
- Side Carrier, adapter kit, TRAX Lock Set
TRAX ADV M Aluminium Case
- Model for the Right side of the motorcycle
- Protection against oxidation and abrasion thanks to black powder coating, easy to clean surface
- Sturdy and watertight Side Case made from aluminium
- Large chamfer on sides for plenty of ground clearance for cornering, additional Protection from glass fiber reinforced plastic corner caps
- Robot-guided welding and self-piercing riveting prevent dampness from getting in
- Even when loaded, completely removable lid with quick-release fastener
- 4 large tie-downs integrated into the lid design (e. g. for a tent or Accessory bag)
- High stability thanks to the embossed patterns, welded edges and pre-installed retaining rail
- Hinges made from stainless steel, handles made from anodized aluminum
- Lid limiters Provide additional stability when using extra Luggage on the lid
- Exchangeable Cover gasket
- The membrane makes it easy to open the lid, even in case of extreme pressure and temperature fluctuations
- Quick Mounting on to all Pro and EVO Luggage carriers (adapters sold separately)
- Adapter kits also available for Mounting on to girders from other manufacturers such as Givi and Hepco & Becker
- A Lock Set with 6 identical locks is available as an option and is not included in delivery
- Details
- Material: Aluminum
- Surface: powder coated
- Color: black
- Size: 49,0 x 23,0 x 37,0 cm / 19.3 x 9.1 x 14.6 in
- Total Weight: appr. 5,1 kg / appr. 11.2 lb
- Total Volume: 37,0 l
- Note
- Also available as a TRAX ADV aluminum case System with 2 Side Cases, bike-specific Side Carriers, adapters and Lock Set.
- Required for Mounting
- Side Carrier, adapter kit, TRAX Lock Set
TRAX Lock Set with Pro anti-theft Protection
- 9 matching locks
- With anti-theft Protection for Pro Side Carrier
- Compatible with Side Cases and Top Cases from the TRAX ADV and TRAX ION series
- One key for all locks
- Details
- Color: black
- Total Weight: appr. 0,5 kg / appr. 1.0 lb
Multi-tool key chain attachment
- Multitool as practical key chain
- Quick-release fastener opener for EVO and Pro Side Carriers
- Hex key (14 mm) - ideal for many motorcycle Mirrors
- Hex keys in four additional sizes (8, 10, 12, 13 mm)
- Bottle opener
- Key chain eyelet
- With laser-etched SW-MOTECH logo
- Details
- Material: Stainless steel
- Surface: brushed
- Color: silver
- Total Weight: appr. 0,0 kg / appr. 0.1 lb
